Primary parameter:
1. output range from 3000 kW to 17550 kW
2. voltage range from 110V to 15000V
3. frequency of 50HZ and 60HZ
Fuels: liquid fuel, gas, etc.
Advantages:
1. automatic switch of fuel modes between liquid fuel and gas without any manual intervention, easy to operate.
2. keeping the engine rpm and load, and highly reducing operation cost
3. emissions are well below the IMO limit and are environmentally friendly.
AGG DUAL FUEL & TRI FUEL GENERATOR SETS PARAMETERS(MAN SERIES) | ||||||||
No. | AGG Type | Engine Type | Engine Output (kW) | Consumption (100%MCR) | Speed (rpm) | Engine Dimensions (appr. L*W*H)(mm) | Engine Weight(appr. Kg) | |
(g/KWh) Liquid Model (g/KWh) | (KJ/KWh) Gas Model (KJ/KWh) | |||||||
1 | AGA3150DF | 6L35/44DF | 3180 | 175.5 | 7470 | 750 | 6485×2539×4163 | 43100 |
2 | AGA3700DF | 7L35/44DF | 3710 | 175.5 | 7470 | 750 | 7015×2678×4369 | 48200 |
3 | AGA4200DF | 8L35/44DF | 4240 | 175.5 | 7470 | 750 | 7545×2678×4369 | 53300 |
4 | AGA4750DF | 9L35/44DF | 4770 | 175.5 | 7470 | 750 | 8075×2678×4369 | 57600 |
5 | AGA5300DF | 10L35/44DF | 5300 | 175.5 | 7470 | 750 | 8605×2678×4369 | 62300 |
6 | AGA5800DF | 6L51/60DF | 5850 | 180 | 7360 | 500 | 8494×3165×5340 | 106000 |
7 | AGA6800DF | 7L51/60DF | 6825 | 180 | 7360 | 500 | 9314×3165×5340 | 119000 |
8 | AGA7800DF | 8L51/60DF | 7800 | 180 | 7360 | 500 | 10134×3165×5340 | 135000 |
9 | AGA8700DF | 9L51/60DF | 8775 | 180 | 7360 | 500 | 11160×3283×5340 | 148000 |
10 | AGA11700DF | 12V51/60DF | 11700 | 180 | 7400 | 500 | 10254×4713×5517 | 187000 |
11 | AGA13600DF | 14V51/60DF | 13650 | 180 | 7400 | 500 | 11254×4713×5517 | 213000 |
12 | AGA15600DF | 16V51/60DF | 15600 | 180 | 7400 | 500 | 12254×4713×5517 | 240000 |
13 | AGA17500DF | 18V51/60DF | 17550 | 180 | 7400 | 500 | 13644×4713×5517 | 265000 |
Remarks:
1. The rated power meets the ISO 3046-1:2002 Standard;
2. The fuel consumption parameters are tested under ISO 3046-1 operating conditions: ambient pressure 1,000mbar, ambient air temperature: 25℃;
3. This sheet is only for technical selection purpose only. AGG reserves the right to change specifications without notice.
