Primary parameter:
1. output range from 5200 kW to 14000 kW
2. voltage range from 110V to 15000V(3) frequency of 50HZ and 60HZ
Fuels: liquid fuel, gas, etc.
Advantages:
1. dual Fuel & Tri Fuel gensets have the advantages of high efficiency, low intake pressure, advanced engine protection system.
2. automatic switch of fuel modes without any manual intervention, and easy to operate.
3. low operating cost: the fuel consumption and gas consumption generally accounts for 7% and 93% respectively, which keeps the engine rpm and load, while highly reduce operating cost.
4. low emission
AGG DUAL FUEL & TRI FUEL GENERATOR SETS PARAMETERS(MAK SERIES) | |||||||||
No. | AGG Type | Engine Type | Mechanical Power (KWm) | Electric Power (kWe) | Heat Rate KJ/KWh | Speed (rpm) | Engine Dimensions (appr.L*W*H)(mm) | Engine Weight(appr. Kg) | |
Liquid Model | Gas Model | ||||||||
1 | AGK5400DF | 6CM46DF | 5400 | 5238 | 8270 | 7572 | 500 | 12783×3450×4732 | 94720 |
2 | AGK6300DF | 7CM46DF | 6300 | 6111 | 8270 | 7572 | 500 | 13507×3450×4732 | 107750 |
3 | AGK7200DF | 8CM46DF | 7200 | 6984 | 8270 | 7572 | 500 | 14231×3450×4732 | 115570 |
4 | AGK8000 | G16CM34 | 8000 | 7800 |
| 7790 | 750 | 8073×2800×4380 | 81400 |
5 | AGK8100DF | 9CM46DF | 8100 | 7857 | 8270 | 7572 | 500 | 14955×3450×4732 | 126000 |
6 | AGK10000 | G20CM34 | 10000 | 9750 |
| 7790 | 750 | 9734×2800×4380 | 93000 |
7 | AGK10800DF | 12CM46DF | 10800 | 10530 | 8227 | 7533 | 500 | 13947×4147×4524 | 162000 |
8 | AGK14400DF | 16CM46DF | 14400 | 14040 | 8227 | 7533 | 500 | 15891×4147×4524 | 215000 |
Remarks:
1. All the parameters are tested under ISO3046/1 operating condition.
2. The parameters concerning output should be otherwise revised supposing not under ISO3046/1 operating condition.
3. This sheet is only for technical selection purpose only. AGG reserves the right to change specifications without notice.
